Production delays do not always come from complex electrical faults. Sometimes, a small mismatch between a cable entry component and an enclosure can slow down an entire assembly l...
READ MOREChina Dental Gauge Data Reference Table
Dental Gauge Data Reference Table Manufacturer
-
Parameters:
Dental gauge metric syste NPT Screw pitch P (mm) Outer diameter of thread D1 (mm) Thread path D2 ...read moreBrand:
Dental Gauge Data Reference Table
-
Parameters:
Dental gauge metric syste NPT Screw pitch P (mm) Outer diameter of thread D1 (mm) Thread path D2 ...read moreBrand:
Dental Gauge Data Reference Table
-
Parameters:
Dental gauge metric syste NPT Screw pitch P (mm) Outer diameter of thread D1 (mm) Lower aperture ...read moreBrand:
Dental Gauge Data Reference Table
-
Parameters:
Dental gauge metric syste NPT Screw pitch P (mm) Outer diameter of thread D1 (mm) Thread path D2 ...read moreBrand:
Dental Gauge Data Reference Table
Dental Gauge Data Reference Table
● Material: South Asia rigid PVC(gray), good insulation, no spontaneous combustion, temperature resistance to 85°C.
● Use structure: It is composed of two parts: the bottom of the groove and the cover of the groove, and the two sides of the bottom groove are provided with line holes.
| Dental gauge metric syste NPT | Screw pitch P (mm) | Outer diameter of thread D1 (mm) | Thread path D2 (mm) | Lower aperture φ(mm) | plate diameter φ(mm) |
| M6 | 1 | 6 | 4.917 | 5.1 | 6~6.3 |
| M8 | 1.25 | 8 | 6.647 | 6.8 | 8-8.3 |
| M10 | 1.5 | 10 | 8.376 | 8.6 | 10~10.3 |
| M12 | 1.5 | 12 | 10.376 | 10.6 | 12~12.3 |
| M14 | 1.5 | 12 | 10.376 | 10.6 | 12~ 12.3 |
| M16 | 1.5 | 16 | 14.376 | 14.6 | 16~16.3 |
| M18 | 1.5 | 16 | 14.376 | 14.6 | 16~16.3 |
| M20 | 1.5 | 20 | 18.376 | 18.6 | 20~20.3 |
| M22 | 1.5 | 20 | 18.376 | 18.6 | 20~20.3 |
| M24 | 1.5 | 20 | 18.376 | 18.6 | 20~20.3 |
| M25 | 1.5 | 25 | 23.376 | 23.6 | 25~25.4 |
| M27 | 1.5 | 25 | 23.376 | 23.6 | 25~25.4 |
| M30 | 1.5 | 25 | 23.376 | 23.6 | 25~ -25.4 |
| M32 | 1.5 | 32 | 30.376 | 30.6 | 32~32.4 |
| M36 | 1.5 | 32 | 30.376 | 30.6 | 32~32.4 |
| M40 | 1.5 | 40 | 38.376 | 38.6 | 40~40.4 |
| M50 | 1.5 | 50 | 48.376 | 48.6 | 50~50.4 |
| M63 | 1.5 | 63 | 61.376 | 61.6 | 63~63.4. |
| M75 | 1.5 | 75 | 73.376 | 73.6 | 75~75.6 |
| M75 | 2 | 75 | 72.835 | 73.1 | 75~75.6 |
| M80 | 2 | 90 | 87.835 | 88.1 | 90~91 |
| M88 | 2 | 90 | 87.835 | 88.1 | 90~91 |
| M100 | 2 | 100 | 97.835 | 98.1 | 100~101 |
| M114 | 2 | 63 | 64 | 74 | 19 |
Dental Gauge Data Reference Table
● Material: South Asia rigid PVC(gray), good insulation, no spontaneous combustion, temperature resistance to 85°C.
● Use structure: It is composed of two parts: the bottom of the groove and the cover of the groove, and the two sides of the bottom groove are provided with line holes.
| Dental gauge metric syste NPT | Screw pitch P (mm) | Outer diameter of thread D1 (mm) | Thread path D2 (mm) | Lower aperture φ(mm) | plate diameter φ(mm) |
| PG7 | 1.27 | 12.5 | 11.28 | 11.4 | 12.5~12.8 |
| PG9 | 1.41 | 15.2 | 13.86 | 14 | 15.2~15.5 |
| PG11 | 1.41 | 18.6 | 17.26 | 17.4 | 18.6~18.9 |
| PG13.5 | 1.41 | 20.4 | 19.06 | 19.2 | 20.4~20.7 |
| PG16 | 1.41 | 22.5 | 21.16 | 21.3 | 22.5~22.8 |
| PG21 | 1.588 | 28.3 | 26.78 | 27 | 28.3~28.7 |
| PG29 | 1.588 | 37 | 35.48 | 35.7 | 37~37.4 |
| PG36 | 1.588 | 47 | 45.48 | 45.7 | 47~47.4 |
| PG42 | 1.588 | 54 | 52.48 | 52.7 | 54~54.4. |
| PG48 | 1.588 | 59.3 | 57.78 | 58 | 59.3-59.7 |
Dental Gauge Data Reference Table
● Material: South Asia rigid PVC(gray), good insulation, no spontaneous combustion, temperature resistance to 85°C.
● Use structure: It is composed of two parts: the bottom of the groove and the cover of the groove, and the two sides of the bottom groove are provided with line holes.
| Dental gauge metric syste NPT | Screw pitch P (mm) | Outer diameter of thread D1 (mm) | Lower aperture φ(mm) |
| NTP1/4 | 1.411 | 13.636 | 11 |
| NPT3/8 | 1.411 | 17.055 | 14.5 |
| NPT1/2 | 1.814 | 21.223 | 17.8 |
| NPT3/4 | 1.814 | 26.568 | 23 |
| NPT1 | 2.208 | 33.227 | 29 |
| NPT11/4 | 2.208 | 41.984 | 38 |
| NPT11/2 | 2.208 | 48.054 | 44 |
| NPT2 | 2.208 | 60.092 | 56 |
Dental Gauge Data Reference Table
● Material: South Asia rigid PVC(gray), good insulation, no spontaneous combustion, temperature resistance to 85°C.
● Use structure: It is composed of two parts: the bottom of the groove and the cover of the groove, and the two sides of the bottom groove are provided with line holes.
| Dental gauge metric syste NPT | Screw pitch P (mm) | Outer diameter of thread D1 (mm) | Thread path D2 (mm) | Lower aperture φ(mm) | plate diameter φ(mm) |
| G1/4 | 1.337 | 13.157 | 11.445 | 11.8 | 13.2~13.4 |
| G3/8 | 1.337 | 16.662 | 14.95 | 15.3 | 16.7~16.9 |
| G1/2 | 1.814 | 20.955 | 18.631 | 19 | 21~21.2 |
| 3/4 | 1.814 | 26.441 | 24.117 | 24.5 | 26.5~26.8 |
| G1 | 2.309 | 33.249 | 30.291 | 30.8 | 33.3~33.6 |
| G1 1/4 | 2.309 | 41.91 | 38.952 | 39.5 | 42~42.3 |
| G1 1/2 | 2.309 | 47.803 | 44.845 | 45.3 | 48~48.4 |
| G2 | 2.309 | 59.614 | 56.656 | 57 | 60~60.4 |
| G2 1/2 | 2.309 | 75.184 | 72.226 | 72.6 | 75.2~75.6 |
| G3 | 2.309 | 87.884 | 84.926 | 85.3 | 88~89 |
